Speaker Specifications |
|
| SpeakerCraft Product No.: | ASM76750 |
| Dimensions: | 11 5/8" diameter x 11" D (295.275mm x 279.4mm) |
| Cut-Out Diameter: | 9 5/8" (244.475mm) |
| Motorized Descent Stops: | 15, 30, and 45 |
| Rotation Range: | 320 |
| Woofer: | 8" Kevlar cone woofer |
| Tweeter: | 1" Aluminum/Magnesium Dome Tweeter |
| Efficiency: | 91dB 1W/1m |
| Frequency Response: | 33Hz - 20kHz ±2dB |
| Power Recommendations: | 5-100 watts, undistorted |
| Impedance: | 8/6/4 ohms, depending on switch setting |
| Connections: | Cat. 5 cable, speaker cable |
| Warranty: | Speaker components: lifetime, limited; electronics: 2 years, limited |
|
Controller Specifications |
|
| SpeakerCraft Product No.: | ASM76000 |
| Dimensions: | 17 1/4" W x 2 1/8" H x 10" D (438.15mm x 53.975mm x 254mm) |
| Control Options: | Via IR and RS232 |
| Tilt Angle Presets: | 0°, 15°, 30° and 45° |
| Warranty: | 2 years, limited |
: - |
